	XLCT

Hydraulic Torque Tool

The XLCT is the world’s best-selling limited clearance industrial bolting system with over one hundred thousand in use around the world. Since 1992, the signature red housing has represented quality, durability, and reliability on job sites in every major industry. From the tallest roller coasters to the world’s largest bridges, the XLCT has the power to get the job done.

Tool Type:

Hydraulic

Radius

1.03" - 3.07"

Weight

2.05 - 23.80 Lbs

Torque Range:

243.00 - 30986.00 ft-lbs

Features

Lock-Up Release

Like the MXT, the XLCT features a lock-up release lever that allows you to release pressure after torqueing for easy removal. (also found on Stealth limited-clearance series)

Zero-Slip Ratchet

The XLCT series features a Zero-Slip ratchet for more powerful breakout and faster tightening. The secondary pawl inside the tool prevents the ratchet from turning opposite of the direction it is being driven.

Multi-Use Accessories

The XLCT series is available with interchangeable cartridges for 6-point hex, 12-point hex, allen drives, square drives, open spanners, and many other configurations to simplify the most challenging bolting jobs.
